12 Strand Marine Anchor Rope With Polyamide Yarn Polyester Material

  • 12 Strand Marine Anchor Rope With Polyamide Yarn Polyester Material
  • 12 Strand Marine Anchor Rope With Polyamide Yarn Polyester Material
  • 12 Strand Marine Anchor Rope With Polyamide Yarn Polyester Material
  • 12 Strand Marine Anchor Rope With Polyamide Yarn Polyester Material
  • 12 Strand Marine Anchor Rope With Polyamide Yarn Polyester Material
  • 12 Strand Marine Anchor Rope With Polyamide Yarn Polyester Material
Place of Origin CHINA
Brand Name JC MARINETIME
Certification ISO / CE
Model Number 3 / 4 / 8 / 12 STRAND ROPE
Minimum Order Quantity 220 Meter
Price 30 USD Per Meters
Packaging Details Pallet Or As Required
Delivery Time 5-20 days
Payment Terms L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability 50000 Meters Per Month

Contact me for free samples and coupons.

WhatsAPP:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Part Dock Mooring Coil Length 220m
Weight And Length Tolerance ± 5% Spliced Strength ±10% Lower
U.V.Resistance Very Good Service OEM/ODM
Warranty 12 Months Material Polyamide Multifilament,Polyamide Yarn,Polypropylene
Color Customers' Requirments,As Your Request,Black,White,optional Length As Customer's Need,Custermized,220m,As Required
Highlight

Polyester Marine Anchor Rope

,

12 Strand Marine Anchor Rope

,

Polyamide Yarn Marine Anchor Rope
You can tick the products you need and communicate with us in the message board.
Specification Specification PA Multifilament PA Multifilament PAYarn PAYarn PPMultifilament PPMultifilament
20 2-1/2 247 81 247 70 189 64
24 3 355 114 355 101 273 89
28 3-1/2 484 152 484 133 373 118
32 4 632 196 632 169 483 148
36 4-1/2 800 245 800 210 614 186
40 5 987 300 987 253 756 226
44 5-1/2 1190 358 1190 303 924 271
48 6 1420 420 1420 355 1092 315
52 6-1/2 1670 489 1670 413 1281 364
56 7 1930 561 1930 473 1491 416
60 7-1/2 2220 640 2220 539 1721 476
64 8 2530 723 2530 603 1943 539
72 9 3200 905 3200 759 2457 676
80 10 3950 1102 3950 928 3045 832
88 11 4780 1326 4780 1106 3686 998
96 12 5690 1561 5690 1301 4379 1178
104 13 6670 1816 6670 1556 5145 1351
112 14 7740 2091 7740 1775 5985 1560
120 15 8880 2387 8880 2027 6B25 1791
128 16 10110 2703 10100 2296 7770 2022
136 17 11400 3040 11400 2584 8820 2276
144 18 12800 3386 12800 2889 9780 2540
160 20 15800 4141 15800 3565 12100 3112
Leave a Message
Specification Specification PA Multifilament PA Multifilament PAYarn PAYarn PPMultifilament PPMultifilament
Product Description

12 Strand Rope Factory Price Nylon Polyester Anchor Marine Rope



1. General Description



QINGDAO JINCHENG MARITIME has serial products including varieties of nylon, polypropylene filament, polypropylene, polypropylene polyester mixed, polyester.Imported Germany technology, the products have advantages of reasonable braided structure, scientific technology, high strength, low elongation, wearing resistance, anti -corrosion and simple operation. the products are mainly used in fields of shipbuilding, ocean transportation, national defense and

military industry, sea petroleum and harbor operation.

12 Strand Marine Anchor Rope With Polyamide Yarn Polyester Material 0

2.Main performance

Material
材料		 Polyamide
Multifilament
锦纶复丝		 Polyamide
Yarn
锦纶线		 Polypropylene
Multifilament
丙纶长丝		 Polypropylene
丙纶		 Polyester
涤纶		 Polypropylene and
Polyester Mixed
涤纶丙纶混合
Spec.Density
比重		 1.14
no floating		 1.14
not floating		 0.91
no floating		 0.91
Floating		 1.27
no floating		 0.95
Floating
Melting Point
熔点		 215℃ 215℃ 165℃ 165℃ 260℃ 165℃/260℃
Abrasion Resistance
耐磨性		 Very Good Very Good Medium Medium Good Good
U.V.Resistance
防紫外线		 Very Good Very Good Medium Medium Good Good
Temperature resistance
使用环境		 120℃max 120℃max 70℃max 70℃max 120℃max 80℃max
Chemical resistance
耐化学腐蚀性		 Very Good Very Good Good Good Good Good





3.Technology Comparison

Coil length: 220m

Spliced strength:± 10% lower

Weight and length tolerance:± 5%

MBL=Minimum Breaking Load conform ISO 2307

Other sizes available upon request

12 Strand Marine Anchor Rope With Polyamide Yarn Polyester Material 1

4.Parameter Table

Specification
规格		 PA Multifilament
锦纶复丝		 PAYarn
锦纶		 PPMultifilament
丙纶长丝		 Polypropylene
丙纶		 Polyester
涤纶		 PET/PP Mixed
丙纶/涤纶混合绳
Dia. Cir Ktex KN Ktex KN Ktex KN Ktex KN Ktex KN Ktex KN
直径 圆 周 线密度 破断强力 线密度 破断强力 线密度 破断强力 线密度 破断强力 线密度 破断强力 线密度 破断强力
20 2-1/2 247 81 247 70 189 64 180 58 303 64 194 70
24 3 355 114 355 101 273 89 260 81 437 91 279 98
28 3-1/2 484 152 484 133 373 118 355 107 594 122 380 133
32 4 632 196 632 169 483 148 460 135 778 157 497 170
36 4-1/2 800 245 800 210 614 186 585 169 982 194 629 214
40 5 987 300 987 253 756 226 720 205 1215 240 776 262
44 5-1/2 1190 358 1190 303 924 271 880 246 1468 285 939 314
48 6 1420 420 1420 355 1092 315 1040 286 1750 336 1110 371
52 6-1/2 1670 489 1670 413 1281 364 1220 331 2050 392 1320 432
56 7 1930 561 1930 473 1491 416 1420 378 2380 448 1520 499
60 7-1/2 2220 640 2220 539 1721 476 1630 433 2730 499 1750 569
64 8 2530 723 2530 603 1943 539 1850 490 3110 579 1990 644
72 9 3200 905 3200 759 2457 676 2340 615 3930 721 2520 805
80 10 3950 1102 3950 928 3045 832 2900 756 4850 884 3110 982
88 11 4780 1326 4780 1106 3686 998 3510 907 5870 1061 3750 1183
96 12 5690 1561 5690 1301 4379 1178 4170 1071 6990 1255 4470 1397
104 13 6670 1816 6670 1556 5145 1351 4900 1228 8220 1448 5260 1622
112 14 7740 2091 7740 1775 5985 1560 5700 1418 9500 1652 6050 1877
120 15 8880 2387 8880 2027 6B25 1791 6500 1628 10900 1902 6980 2142
128 16 10110 2703 10100 2296 7770 2022 7400 1838 12400 2152 7950 2417
136 17 11400 3040 11400 2584 8820 2276 8400 2069 14000 2448 8950 2713
144 18 12800 3386 12800 2889 9780 2540 9400 2309 15700 2703 10100 3029
160 20 15800 4141 15800 3565 12100 3112 11521 2829 19400 3335 12500 3703
