Heavy Duty Sling Type Marine Rubber Fender with High Energy Absorption, Easy Installation, and Corrosion Resistance for Ship Docks
| Place of Origin | China |
|---|---|
| Brand Name | JC MARINETIME |
| Certification | CCS.ABS.LRS.BV.GL.DNV.NK.RMRS |
| Model Number | Diameter 0.5m~3.3 m,Length 1m~6.5m |
| Minimum Order Quantity | 1 PC |
| Price | USD 800~1200 PER PIECE |
| Packaging Details | 1. Bare packed: packed in bundles 2. Packed in iron drums then on pallets 3. Packed in woodencase 4. Required by cllent shipping |
| Delivery Time | 10-45 Days |
| Payment Terms | T/T,Western Union,L/C,MoneyGram,D/A,D/P |
| Supply Ability | 5000-10000 Metric PC/Metric PCs Per Year |
Product Details
| Warranty | 24 Months | Function | Absorb Impact Energy |
|---|---|---|---|
| Material | Rubber | Process | Extrusion |
| Installation | Easy To Install And Replace | Working Temperature | -60-200℃ |
| Shape | Cylindrical | Durability | Long-lasting |
| Elasticity | High | Packing | Normal Packing |
| Color | Black | Maintenance | Low |
| Logo | Customized Logo | ||
| Highlight | heavy duty marine rubber fender,slings type ship dock fender,high energy absorption marine fender |
||
Product Description
Heavy Duty Sling Type Rubber Marine Anti-collision Buffer Fender for Ship Dock
ISO9001, BV, CCS, RS, IRS, ABS Certified
The Sling Type Fender is a lightweight and convenient derivative of the inflatable fender. Its core feature uses dedicated high-strength slings instead of traditional chains or frames for lifting and fixation. Designed for flexible deployment, quick installation, and compatibility with small to medium-sized vessels or temporary berths.
Product Overview
Material Advantages:
- Main material is synthetic rubber (natural rubber and styrene-butadiene rubber blend) with excellent elasticity for efficient energy absorption
- Rubber material resists seawater, UV radiation, and acid/alkali corrosion for harsh marine environments
- Internal structure uses high-strength nylon cord fabric reinforcement for improved tensile strength and tear resistance
Performance Benefits:
- High energy absorption + low reaction force: 70%-90% energy absorption rate vs. 40%-60% for traditional planks; reduces reaction force to 1/3-1/5 of rigid planks
- Excellent elasticity: Significant deformation with quick recovery; performs well at compression angles
- Adjustable air pressure: 0.02-0.15MPa range adapts to different tonnage, speed, and sea conditions
- Lightweight installation: Much lighter than solid planks; compact storage when deflated
- Self-floating design: Automatically adjusts with tide changes; ideal for ports with large tidal differences
Manufacturing Process:
- Raw material preparation: Rubber compounding with reinforcing agents and antioxidants
- Molding process: Winding process ensures uniform, tight structure
- Vulcanization treatment: High temperature/pressure bonding for stability and durability
- Assembly and inspection: Installation of valves/flanges with comprehensive testing
Key Features
- Lightweight hoisting: Integrated polyester/nylon slings (10-20 ton strength); 60% faster installation than chain-fixed systems
- Low-damage design: Soft sling material prevents hull scratches and dock wear; ideal for yachts and fiberglass vessels
- Small-tonnage optimization: Diameter 0.5-2m, length 1-4m; 75%-85% energy absorption for 500-5000 ton vessels
- Cost-effective storage: Deflated volume reduced to 1/10 original size; 30% lower logistics costs
- Weather resistance: CR or IIR rubber construction; 8-15 year service life in salt spray and extreme temperatures (-30℃ to +60℃)
- Flexible combination: Can be used individually or connected for continuous buffering belts
Technical Parameters
Applications
- Port terminals: Berth edge protection for container, bulk cargo, and oil terminals
- Shipping sector: Berthing buffer for freighters, tankers, warships, and ship-to-ship collision protection
- Offshore facilities: Perimeter protection for platforms, buoys, and drilling platforms
- Specialized scenarios: Temporary docks, offshore construction areas, and LNG carrier protection
Support and Services
- 24/7 Customer Support: Technical consultation for specification selection, usage methods, and maintenance
- Regular Follow-up: Manufacturer visits to collect feedback and improve product quality
- Maintenance Guidance: Professional support for inspection, cleaning, lubrication, and repair procedures
With excellent quality and attentive service, we provide solid guarantees for your maritime operations. Choosing us means choosing safety, efficiency, and worry-free operation. Any questions? Our JinCheng Maritime team provides 24/7 support.
